Location
Nicaragua
Building Area
294 m²
Industry
Warehouse & Logistics
Completion
2025
Project Overview
A compact steel warehouse building delivered as a turnkey export package to Nicaragua, built around a single-skin steel sheet envelope with thermal insulation cotton and an office mezzanine deck, engineered from customer-provided drawings for practical storage and utility use.
Project Highlights
Compact 21m × 14m footprint suited to small industrial storage
Single-skin steel sheet envelope with thermal insulation cotton
Office mezzanine decking sheet integrated into the package
Clear internal height for loading and operational flexibility
Customer-drawing-based engineering coordination
Galvanised purlins and girts for corrosion resistance
Total area: 294 m²
Project Timeline
Design & Engineering
Environmental analysis, structural design, MEP coordination
Steel Fabrication
Precision fabrication with zero-defect welding
Shipping & Logistics
Sea freight to Corinto port, Nicaragua
On-Site Erection
Steel erection, panel cladding, MEP integration
Project Gallery
View Full Size
View Full Size
View Full Size
View Full Size
View Full Size
Technical Specifications
Structural System
Portal Frame
Dimensions
21m × 14m × 8.5m
Floor Area
294 m²
Wall System
0.5mm PPGI single-skin steel sheet + 10mm thermal insulation cotton; office mezzanine decking sheet
Roof System
0.5mm PPGI single-skin steel sheet + 10mm thermal insulation cotton
Design Load
Per customer-provided drawings
Primary Steel
Q355B (= S355JR / ASTM A572 Gr.50, Painted)
Secondary Steel
Q235B (= S235JR / ASTM A36, Galvanized)
Project Information
Location
Nicaragua
Building Type
Warehouse
Area
294 m²
Completion Year
2025
Industry
Warehouse & Logistics
